Specifications
- Manufacturer:Yamaha
- Model:Raptor 700R Team Yamaha Blue
- Year:2024
- Type:Pure Sport
- Engine:Liquid Cooled, Sohc, 4-valve, Single
- Displacement:686cc
- Bore And Stroke:102 X 84mm
- Compression Ratio:10.0:1
- Fuel Delivery:Yamaha Fuel Injection (yfi), 44mm
- Ignition:Tci: Transistor Controlled Ignition
- Starting:Electric
- Lubrication:Dry Sump
- Transmission:5-speed With Reverse; Wet Multiplate Clutch
- Final Drive:X-ring Chain; 2wd
- Suspension (front):Independent Double Wishbone With Piggyback High/low-speed Compression, Rebound And Threaded Preload Adjustment, 231 Mm (9.1″) Travel
- Suspension (rear):Cast Aluminum Swingarm With Piggyback High/low-speed Compression, Rebound And Threaded Preload Adjustment, 257 Mm (10.1″) Travel
- Brakes (front):Dual 161 Mm Discs / Twin Piston Calipers
- Brakes (rear):Single 200 Mm Disc / Twin Piston Caliper
- Tires (front):Maxxis, At22 X 7-10
- Tires (rear):Maxxis, At20 X 10-9
- Length:1,845mm (72.6″)
- Width:1,155 Mm (45.5″)
- Height:1,115 Mm (43.9″)
- Wheelbase:1,280mm (50.4″)
- Minimum Ground Clearance:113mm (4.4″) Rear Sprocket Protector / 240 Mm (9.4″) Engine
- Seat Height:830 Mm (32.7″)
- Wet Weight:191kg (422 Lb)
- Fuel Capacity:11 Litres
- Colour(s):Team Yamaha Blue
- Warranty:6 Months (unlimited Mileage)
